AST - EARTHQUAKE-RESISTANT BEAM CLAMP FOR IRON GIRDERS

AST – EARTHQUAKE-RESISTANT BEAM CLAMP FOR IRON GIRDERS

It is used to set up lateral and longitudinal supports.

It is suitable to set up earthquake-resistant supports – either lateral or longitudinal – when combined with “AGG SM” universal joint.
Thanks to the locking bolt – which head’s breakage is calibrated – supports installation is quick and handy.
At the building site no torque wrench is needed to tighten the beam clamp.
It is FM approved.
It is compliant with NFPA®-13 regulations for American earthquake-resistant supports.

MATERIAL = Steel DX51D EN 10142 with electro zinc-plating FM - UL approved

COD	Type	Description
161752	AST	For iron girders	Aggiungi / Rimuovi

COD	Type	A	B	R
161752	AST	63,5	69,9	6,4 - 19,1	Aggiungi / Rimuovi

Venduti in Cardboard box

COD	Type	Pieces pack
161752	AST	1	Aggiungi / Rimuovi
